10-amp MPPT Solar Controller

The GP-MPPT-60/10 optimizes solar charging capacity in mobile systems in all sun and tilt conditions while allowing the use of simpler series wiring configurations up to 100V (Voc @ STC).

10-amp MPPT Solar Controller

The GP-MPPT-60/10 optimizes solar charging capacity in mobile systems in all sun and tilt conditions while allowing the use of simpler series wiring configurations up to 100V (Voc @ STC).

Solar Controller maintains the life of the battery by protecting it from overcharging. When your battery has reached a 100% state of charge, the controller prevents overcharging by limiting the current flowing into the batteries from your solar array. The GP-MPPT-60/10 optimizes solar charging capacity in mobile systems in all sun and tilt conditions while allowing the use of simpler series wiring configurations up to 100V (Voc @ STC).

MODEL: GP-MPPT-60/10

Use a solar controller to maintain a battery’s life by limiting the current flowing into it once it is fully charged.
  • Advanced multi-peak tracking technology, allowing for better charging in shaded areas
  • Maximum power point tracking (MPPT) charging for higher energy efficiency, as much as to 20% more than traditional PWM charging
  • MPPT tracking allows up to 99.9% efficiency.
  • Energy conversion efficiency up to 98%
  • Supports lithium, sealed, vented, AGM, and flooded Lead Acid batteries
  • Current-limited charging mode
  • Automatic lead-acid battery voltage detection
  • LED indicators
  • Built-in over-temperature protection
  • Temperature compensation and automatic adjustment of charge and discharge parameters
  • Solar panel short circuit protection
  • Battery open circuit protection
  • TVS transient protection.
  • IP67 (waterproof) rated.
  • RS485 connection
  • Aluminum housing
  • 5-year warranty

System Voltage

12/24V (auto-recognition)

Temperature Compensation

-25mV / K (12V systems), – 50mV/K (24V Systems)

Battery Voltage Range (min. – max.) [V]

9V – 15.5V (12V system), 18 – 31V (24V system)

Max Charge Current

20A

Float Charge (Default= SEALED)

13.8/27.6V (25°C)

Main Charge (Default= SEALED)

14.1/28.2V (25°C), 0.5h Daily

Boost Charge (Default- SEALED)

14.4/28.8V (25°C), 2h, Activation: Battery Voltage <12.3/24.6V

Equalization Charge (Flooded)

14.9/29.8 (25°C),2h, Activation: Battery Voltage <12.1/24.2V (at least every 30 days)

Dimensions

88.5 x 112 x 41.4 mm

Weight

1.38lbs

Type of Protection

IP68

Warranty

5 Years
