6 Volt Sun Cycle AGM Solar Battery

The Go Power! 6 Volt Sun Cycle AGM Solar Battery is designed specifically for solar and inverter use. This tried and tested technology is great for installations in colder climates.

Category:

MODEL: GP-AGM-224-6V

Upgrade your system with the Go Power! AGM deep cycle battery designed specifically for solar!

Features

  • 6V, 224AH @ C20
  • Float application: 6.8 – 6.9V
  • Cycle application: 7.2 – 7.4V
  • Maintenance-free, sealed construction
  • Spill-proof/leak-proof (VRLA)
  • Integrated carrying handles
  • UL recognized
  • 67.3 lbs
  • 2-year warranty

SPECIFICATIONS

Technology

AGM, VRLA deep cycle battery

Nominal Voltage

6 V

Nominal Capacity

224 Ah

Rated Capacity (25oC)

224 Ah/11.2A (20hr, 5.25V/cell)

194 Ah/19.4A (10hr, 5.25V/cell)

179 Ah/35.9A (5hr, 5.1V/cell)

Nominal Operating Temperature

77 ±5 °F (25 ±3 °C)

Operating Temperature Range

Discharge, Storage: -4~140°F (-20~60°C)

Charge: -4~122°F (-20~50°C)

Capacity Correction for Temperature Variations

104°F (40°C) 103%

77°F (25°C) 100%

32°F (0°C) 85%

Maximum Discharge Current

2000 A (5s)

Internal Resistance

Approx. 1.4mΩ

Terminals

T11

Brass Insert

Cycle Use

Initial Charging Current less than 30.0 A

Voltage: 7.2 V~7.4 V at 77°F (25°C)

Standby Use

No limit on Initial Charging Current

Voltage: 6.8 V~6.9 V at 77°F (25°C)

Certifications

UL; CE; IEC60896-21 & 22

Self Discharge

Batteries can be stored for up to 6 months before a freshening charge is required.

*Batteries stored at temperatures greater than 77°F (25°C) will require a recharge sooner.

Cycle Life

77oF (25oC)

100% Depth of Discharge ~ 250 cycles

50% Depth of Discharge ~ 1100 cycles

30% Depth of Discharge ~ 2250 cycles



Materials

Case and Cover

ABS

Separator

Absorbent Glass Mat (AGM)

Active

PbO2 + Pb

Electrolyte

Diluted Sulfuric Acid

Venting Valve

Rubber, opening pressure 8-20kPa



Mechanical

Length

10.24 in / 260 mm

Width

7.09 in / 180 mm

Height

9.72 in / 247 mm

Total Height

(including terminals)

9.96 in / 253 mm

BCI Group #

27

Weight

67.25 lbs / 30.5 kg

Carrying

Nylon Strap
